Gutter Frost Protection

Our gutter heating parallel circuit self regulating heating cables are inherently temperature safe and can be cut and terminated on site to suit the required application. The gutter heating can be fixed using stainless steel gutter clips or if lead gutters welded clips are provided. It is recommended that these should be fixed at a max of every 1mtr

Only when you have gutters over 600mm will you require multiple gutter heating cables.

The Cables come as a standard 230V however 110V are available, All cables are manufactured to meet BS6351 Grade 2.2 and are both VDE and UL approved.

Product Guide

Gutter Frost Protection

Specification

Product Trace20J
Watts per Mtr 24W/mtr @ 5°C
Max Circuits 100mtrs @ 20A​
Breaker ​Type C
Max Distance between runs 12" - 300mm
​Minimum Installation temp ​-40°C

Notes

If gutter heating cables are less than 3meters then double tracing the pipe can be quicker for installation and material cost by not using terminations or junction boxes.

Insulation displacement connectors can be used with the gutter heating cable

Always add a meter of heating cable per installation

Accessories

Gutter Clips Every 1000mm max
Thermostat SA1 (Air sensing)
Termination Kit​ TracekitJ​
Bracket for Thermostat ​BracketStat (optional)​
PDF

Download the Gutter Frost Protection data sheet Adobe PDF
